ELECTRICAL
- Universal 120-277V AC voltage (50-60Hz).
- 0-10VDC dimming driver.
- Input transient surge protection = 1kV.
- Power Factor > 0.9.
- Total Harmonic Distortion < 20%.
OPTICAL SYSTEM
- Efficacy 140 Lumens per Watt.
- Field selectable 2700K, 3000K, 3500K, 4000K, 5000K, and 6500K color temperatures.
- Selectable output delivers from 2,536 to 5,125 nominal lumens, with 3 settings.
- Long-life LEDs provide 175,000 hours of operation with at least 70% of initial lumen output (L70), and 54,000 hours with at least 90% of initial lumen output (L90).
- LED color maintenance < -0.0006 chromaticity shift (Δu’v’) over the initial 6,000 hours
of operation. - Beam Angle 110°.
- Plastic lens.
- Color rendering index > 80.
MOUNTING
- Recessed mounting (T-grid) is standard.
CODE COMPLIANCE
- cULus listed for damp locations.
- Complies with FCC Part 15, Class A.
WARRANTY
- 5-year warranty on all electronics and housing.
