LED Stairwell Luminaire Lumen & Kelvin Field Selectable

FEATURES

• Field selectable 3500k (warm/neutral white), 4000k (neutral white), and 5000k (cool white) color temperatures*
• Long-life LEDs provide 190,000 hours of operation with at least 70% of initial lumen output (L70), and 58,000 hours with at least 90% of initial lumen output (L90)**
• Selectable lumen outputs range from 4200 nominal lumens to 6000 nominal lumens
• Universal 120-277 AC voltage (50-60Hz) is standard
• 0-10vdc dimming drivers are standard
• Power factor > 0.90
• Total harmonic distortion < 20%
• Color rendering index > 80
• Painted steel housing and PMMA (polymethyl methacrylate) frosted lenses are standard
• Specifically designed to sense motion and illuminate both up and down stairwells (see figure 1)
• Optional occupancy dimming sensor available
• Easy installation in new construction or retrofit

MOUNTING OPTIONS

• Surface Mounting

WARRANTY/LISTING

• cULus listed for damp locations ambient temperatures from-20°C to 50°C (-4°F to 122°F)

• cULus 1598 and 924 listed

• Complies with FCC Part 15, class A

• Complies with IEEE C.62.41-1991, input transient protection (2.0kV)

• 5-Year Warranty of all electronics and housing
