LED Square Ceiling Luminaires 12″ or 14″, 3K, 1000-1500 Lumens, ETL Listed, 5 Year Warranty

HOUSING

• Steel housing and polycarbonate lens

ELECTRICAL

• 120 AC voltage (60Hz) is standard.
• 11”/12” models = 14 nominal watts. 14” models = 20 nominal watts.
• Triac dimming drivers are standard.
• Power factor > 0.90.

OPTICAL SYSTEM

• Field selectable 2700k (soft white), 3000k (warm white), 3500k (warm/neutral white), 4000k (neutral white), and 5000k (cool white) color temperatures.
• Long-life LEDs provide at least 70% of initial lumen output (L70) for 157,000 hours of operation. *
• SMR-KFS provides a range of 1,000 (11”) to 1,400 (14”) nominal lumens and 70 lumens per watt.
• SMS-KFS provides a range of 1,000 (12”) to 1,500 (14”) nominal lumens and 73 lumens per watt.
• Color rendering index (Ra) > 80.

MOUNTING

• Easy installation in new construction or retrofit applications.

CODE COMPLIANCE

• cETLus listed for damp locations.
• Energy Star certified.
• Complies with FCC Part 15, class B.
• Surge protection (0.5kV).

WARRANTY

• 5-year warranty on all electronics and housing.
