MOUNTING
- Universal knockout pattern on back plate for surface mount.
- Suitable for wall or ceiling mount.
- Knockouts provided for conduit feed applications.
- Spacing: 17-ft center-to-center spacing with 3-ft path of egress at 7.5 mounting
height.
HOUSING
- Injection molded, engineering grade, 5VA flame retardant, high impact resistant,
thermoplastic in white finish.
ELECTRICAL
- Dual 120/277 voltage.
- Unique LED indicator light alerts occupant on battery condition (Red-normal, OFF – check battery).
- Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.
- 3.6V 700mAH long-life, maintenance-free, rechargeable Ni-Cd battery.
- Internal solid-state transfer switch automatically connects the internal battery to LED lamp heads for minimum 90-minute emergency illumination.
- Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.
ILLUMINATION
- Ultra-bright, energy efficient, long-life White LED adjustable lamp heads provide up to 30-ft center-to center spacing with 3-ft path of egress at 10-ft mounting height.
- 1.5 watt (3 LEDs x 0.50 watt) per head.
- Unique all-inclusive lamp, reflector and lens assembly.
CODE COMPLIANCE
- UL Listed for damp locations (0°C – 40°C)
- Meets UL924, NFPA 101, Life Safety Code, NEC, OSHA, Local and State Codes.
WARRANTY
- 5-year warranty on all electronics and housing.
