3″ Flat Panel – Kelvin Field Selectable

HOUSING

• Premium powder-coat, aluminum, white housing.

ELECTRICAL

• Operating temperature (ambient): -20°C to 45°C (-4°F to 113°F).
• Universal 120V AC voltage (60Hz) is standard.
• Triac dimming.
• Beam angle 120°.
•  Input transient surge protection = 0.5kV.
• Type IC.
• Power factor > 0.90.
• Total Harmonic distortion < 20%.

OPTICAL SYSTEM

• Polystyrene lens.
• Field selectable 2700k (soft white), 3000k (warm white), 3500k (warm/neutral white), 4000k (neutral white) and 5000k (cool white) color temperatures*.
• Provide a range delivers 400 to 1400 nominal lumens*.
• Long-life LEDs provide 139,000 hours of operation with at least 70% of initial lumen output (L70)**.
• Color rendering index > 90%.

MOUNTING

• Recessed ceiling, new construction or retrofit.
• No recessed housing required for installation.
• Access above ceiling required.
• Covered ceiling mount only.

CODE COMPLIANCE

• cETLus listed for wet locations not exceeding 45°C (113°F).
• Complies with FCC part 15, class B.

WARRANTY

• 5-year warranty on all electronics and housing.
