HOUSING
- White powder-coated steel housing.
ELECTRICAL
- Operating temperature (ambient): -20°C to 50°C (-4°F to 122°F).
- 120-277VAC, 50-60Hz.
- 0-10V dimming driver.
- Input transient surge protection: 1kV.
- Power factor > 0.90.
- Total harmonic distortion (THD) < 20%.
OPTICAL SYSTEM
- Efficacy up to 163 lumens per watt.
- Field-selectable 3000K, 3500K, 4000K, 5000K, and 6500K color temperatures.
- Selectable output delivers from 2,334 to 4,664 lumens across 4 settings.
- Long-life LEDs provide 102,000 hours of operation with at least 70% of initial lumen output (L70), and 54,000 hours with at least 90% of initial lumen output (L90).
- LED color maintenance < 0.0013 chromaticity shift (Δu’v’) over the initial 6,000 hours of operation.
- PMMA (Polymethyl methacrylate) LED lenses for optimal light distribution, efficiency and longevity.
- Color Rendering Index (CRI) ≥ 80.
MOUNTING
- Recessed mounting in grid ceilings is standard.
*Retrofits into most existing center basket housings in about 15 minutes.
*Minimum depth of 3” is necessary to allow proper clearance and installation.
CODE COMPLIANCE
- cULus listed for damp locations.
- Complies with FCC Part 15, Class A.
WARRANTY
- 5-year warranty on all electronics and housing.
