HOUSING
- White Fiberglass housing with stainless steel latches.
ELECTRICAL
- Operating temperature (ambient): -40°C to 40°C (-40°F to 104°F).
- Universal 120-277V AC voltage (50-60Hz).
- 0-10VDC dimming.
- Input transient surge protection = 4kV.
- Power Factor > 0.90.
- Total Harmonic Distortion < 20%.
OPTICAL SYSTEM
- Efficacy up to 165 Lumens Per Watt.
- Field selectable 3500K, 4000K, and 5000K color temperatures.
- Selectable output delivers from 9,723 to 13,855 nominal lumens, with 3 settings.
- Long-life LEDs provide 173,000 hours of operation with at least 70% of initial lumen output (L70), and 52,000 hours with at least 90% of initial lumen output (L90).
- LED color maintenance < -0.0009 chromaticity shift (Δu’v’) over the initial 6,000 hours of operation.
- Acrylic lens.
- Color Rendering Index > 80.
MOUNTING
- Surface mount brackets included.
- Optional cable mount kit provides luminaire suspension.
CODE COMPLIANCE
- cETLus listed for wet locations.
- Complies with FCC Part 15, Class A.
- IP69K rated for ingress protection.
- IK07 rated for impact protection.
WARRANTY & LISTINGS
- 5-year warranty on all electronics and housing.
