HOUSING
- Premium powder-coat, die cast aluminum, Bronze housing.
ELECTRICAL
- Operating temperature (ambient): -40Ā°C to 50Ā°C (-40Ā°F to 122Ā°F).
- Universal 120-277 AC voltage (50-60Hz) is standard.
- 0-10V DC dimming drivers are standard.
- Integrated photocell is standard. Photocell can be enabled or disabled by switch.
- Input transient surge protection = 6kV.
- PF > 0.9; THD < 20%.
OPTICAL SYSTEM
- Polycarbonate lens.
- Field selectable 3000K (warm white), 4000K (neutral white) and 5000K (cool white) color temperatures.
- Four lumens selectable output delivered from 9,888 to 18,713 nominal lumens.
- Long-life LEDs provide 159,000 hours of operation with at least 70% of initial lumen output (L70), and 48,000 hours with at least 90% of initial lumen output (L90).
- Two modules can independently rotate -15Ā° to 210Ā°.
- Sensor-ready receptacle comes standard. Screw-in sensor and remote control sold separately. Remote control required to change factory sensor settings.
- LED chromaticity based on < 6-step ANSI quadrangles.
- LED color maintenance < 0.0008 chromaticity shift (Īuāvā) over the initial 6,000 hours of operation.
- Color Rendering Index > 80.
MOUNTING
- Wall mounting kit.
CODE COMPLIANCE
- cULus listed for wet locations.
- DLC premium listed.
- Complies with FCC Part 15, class A.
- IP65 rated for ingress protection.
- IK08 rated for impact protection.
WARRANTY
- 5 year warranty on all electronics and housing.
