Economy Wall Pack – 2,009 to 3,923 Lumens – Lumen &a Kelvin Field Selectable

The Economy Wall Pack features a bronze die-cast aluminum housing with a polycarbonate lens and selectable 3000K, 4000K, or 5000K color temperatures. It delivers 2,009–3,923 lumens and includes an integrated on/off photocell. It also features field-selectable CCT (3000K/4000K/5000K).

HOUSING

• Premium powder-coat, die cast aluminum, Bronze housing.

ELECTRICAL

• Operating temperature (ambient): -30°C to 50°C (-22°F to 122°F) .
• Universal 120-277 AC voltage (50-60Hz) is standard.
• 0-10V DC dimming drivers are standard.
• Integrated photocell is standard. Photocell can be enabled or disabled by switch.
• Input transient surge protection = 2kV.
• Power factor > 0.90.
• Total Harmonic distortion < 20%.

OPTICAL SYSTEM

• Polycarbonate lens.
• Field selectable 3000K (warm white), 4000K (neutral white) and 5000K (cool white)
  color temperatures.
• Provides a range of 2,009 to 3,923 nominal lumens.
• Long-life LEDs provide 153,000 hours of operation with at least 70% of initial lumen
  output (L70), and 46,000 hours with at least 90% of initial lumen output (L90).
• LED chromaticity based on < 6-step ANSI quadrangles.
• LED color maintenance < -0.0021 chromaticity shift (Δu’v’) over the initial 6,000
  hours of operation.
• Color Rendering Index > 80.

MOUNTING

• Wall mounting kit.

CODE COMPLIANCE

• cULus listed for wet locations.
• Complies with FCC Part 15, class A.
• IP65 rated for ingress protection.
• IK08 rated for impact protection.

WARRANTY

• 5-year warranty of all electronics and housing.
