HOUSING
- Light gray polycarbonate housing with stainless steel latches
ELECTRICAL
- Operating temperature (ambient): -40°C to 50°C (-40°F to 122°F).
- Universal 120-277V AC voltage (50-60Hz) is standard.
- 0-10VDC dimming drivers are standard.
- Input transient surge protection = 2kV.
- Power factor > 0.90.
- Total Harmonic distortion < 20%.
OPTICAL SYSTEM
- Polycarbonate lens.
- Field selectable 3500K (warm white), 4000K (neutral white) and 5000K (cool white) color temperatures.
- Tri-lumen selectable delivers 9,386 to 12,716 nominal lumens.
- Long-life LEDs provide 174,000 hours of operation with at least 70% of initial lumen output (L70), and 53,000 hours with at least 90% of initial lumen output (L90).
- Sensor-ready receptacle standard.
- Screw in sensor ready. Remote control required for programming (Sensor and remote control sold separately).
- LED color maintenance < -0.0005 chromaticity shift (Δu’v’) over the initial 6,000 hours of operation.
- Color rendering index > 80.
MOUNTING
- Surface mount kit is standard and v-hooks included. (Chain not included.)
- Optional cable mount kit provides luminaire suspension.
- Easy installation in new construction or retrofit application.
WARRANTY & LISTINGS
- cULus listed for wet locations.
- Complies with FCC Part 15, class A.
- IP66 rated for ingress protection.
- IK10 rated for impact protection.
- 5-year warranty on all electronics and housing.
