6″ Module – KFS

Housing

• Operating temperature (ambient): -20°C to 45°C (-4°F to 113°F).
• Universal 120V AC voltage (60Hz) is standard.
• 06-MODR4-7L-KFS = 10W
• 06-MODR6-10L-KFS = 14W
• Triac dimming.
• Type IC.
• Input transient surge protection = 0.5kV.
• Power factor > 0.90.
• Total Harmonic distortion < 20%.

Optical System

• Polycarbonate diffuser.
• Field selectable 2700k (soft white), 3000k (warm white), 3500k (warm/neutral white),
4000k (neutral white) and 5000k (cool white) color temperatures*.
• Provide a range delivers 700 to 1,200 nominal lumens*.
• Long-life LEDs provide 139,000 hours of operation with at least 70% of initial lumen
output (L70), and 42,000 hours with at least 90% of initial lumen output (L90)**.
• LED color maintenance < -0.005 chromaticity shift (Δu’v’) over the initial 6,000 hours of
operation.
• Beam angle 110°.
• Color rendering index > 90

Mounting

• Recessed in housing.
• Retrofits in existing incandescent can housing.
• E26 screw base adapter connects directly to standard socket.
• For use in 4” or 6” recessed new construction and remodel housings.

Warranty & Listings

• cETLus listed for damp locations.
• Energy Star certified.
• Complies with FCC part 15, class B.
• Complies with Title 24.
• 5 year warranty on all electronics and housing.
