4" Flat Panel Round Baffled - Fire Resistant - Kelvin Field Selectable

4″ Flat Panel Round Baffled – Fire Resistant – Kelvin Field Selectable

Model: 10-FPRBFR4-10L-5CCT

Ask for Price

Request product pricing

Call for Pricing now: 877.664.5483

Call for pricing now

This field is for validation purposes and should be left unchanged.

Name(Required)

Email(Required)

Phone(Required)

This field is hidden when viewing the form

Division

This field is hidden when viewing the form

Form Name

This field is hidden when viewing the form

Product URL

CAPTCHA

Build an online quote instead

Our lighting professional will call you to provide pricing.

How to request a quote?

1. Click on “Add to Quote”
2. Add as many products as you want to your quote.
3. Go to your Cart at the top right corner of the screen.
4 Sign In or create an account.
5. Submit your quote.
6. A lighting rep will provide pricing within 24 hours.

HOUSING

White powder-coated aluminum housing.

ELECTRICAL

Operating temperature (ambient): -20°C to 45°C (-4°F to 113°F).
120V AC voltage (60Hz) is standard.
10-FPRBFR4-10L-5CCT = 12W
Triac dimming.
Beam angle 120°.
Input transient surge protection = 1 kV.
Type IC.
Power factor > 0.90.
Total Harmonic distortion < 20%.

OPTICAL SYSTEM

Plastic diffuser.
Field selectable 2700K, 3000K, 3500K , 4000K, and 5000K color temperatures.
10-FPRBFR4-10L-5CCT delivers from 933 to 1,036 nominal lumens.
Long-life LEDs provide 191,000 hours of operation with at least 70% of initial lumen output (L70), and 58,000 hours with at least 90% of initial lumen output (L90).
LED color maintenance < 0.0013 chromaticity shift (Δu’v’) over the initial 6,000 hours of operation.
Beam Angle 120°.
Color rendering index > 90%.

MOUNTING

Recessed ceiling, new construction or retrofit.
No recessed housing required for installation.
Access above ceiling required.
Covered ceiling mount only.

CODE COMPLIANCE

cETLus listed for wet locations.
Complies with FCC part 15, class B.
Energy Star certified.
Complies with Title 24.
Inherently protected.
Fire resistant for up to 2 hours. Tested in accordance with UL 263, ASTM E119, and CAN/ULC S101.

WARRANTY
