4″ Disk Light – Occupancy Sensor – 5CCT Kelvin Field Selectable

HOUSING

• Premium powder-coat, steel, white housing.

ELECTRICAL

• Universal 120V AC voltage (60Hz) is standard.
• Triac dimming.
• Input transient surge protection = 0.5kV.
• Power factor > 0.90.
• Total Harmonic distortion < 20%.

OPTICAL SYSTEM

• Polycarbonate diffuser.
• Field selectable 2700k (soft white), 3000k (warm white), 3500k (warm/neutral white), 4000k (neutral white) and 5000k (cool white) color temperatures.
• 06-DK4-8L-KFS-OS to provide a range delivers 770 to 812 nominal lumens.
• Long-life LEDs provide 139,000 hours of operation with at least 70% of initial lumen output (L70), and 42,000 hours with at least 90% of initial lumen output (L90).
• Beam angle 110°.
• Integrated PIR occupancy sensor standard.
• Sensor hold-time adjustable by switch.
• Color rendering index > 90.

MOUNTING

• Surface mounting and retrofit installation.
• Covered ceiling mount.

CODE COMPLIANCE

• cETLus listed for wet locations.
• Energy Star certified.
• Complies with FCC part 15, class B.
• Complies with Title 24.

WARRANTY

• 5-year warranty on all electronics and housing.
