HOUSING
- White power-coated steel housing.
ELECTRICAL
- High ambient operating temperature up to 50°C.
- Universal 120-277V AC voltage (50-60Hz).
- 0-10VDC dimming driver.
- Input transient surge protection =1kV.
- Optional Emergency drivers are available.
- Type IC-rated.
- Power Factor > 0.9.
- Total Harmonic Distortion < 20%.
OPTICAL SYSTEM
- Efficacy 137 Lumens per Watt.
- Field selectable 3000K, 3500K, 4000K, 5000K, and 6500K color temperatures.
- Selectable output delivers from 2,882 to 4,465 nominal lumens, with 3 settings.
- Long-life LEDs provide 180,000 hours of operation with at least 70% of initial lumen output (L70), and 54,000 hours with at least 90% of initial lumen output (L90).
- LED color maintenance <0.0007 chromaticity shift (Δu’v’) over the initial 6,000 hours of operation.
- Plastic lens.
- Color Rendering Index > 80.
MOUNTING
- Recessed mounting in grid ceilings is standard.
- Standard earthquake clips provide secure installation in grid ceilings.
- Optional Surface Mounting Kits (10-SMKT-22S) and Flange Mounting Kits (10-FLANGEKIT22-ET) provide for installation on plaster or other hard ceilings
- Optional Cable Mounting Kits (10-PNL-CM) provide additional security, as well as suspended mounting.
CODE COMPLIANCE
- cULus listed for damp locations and insulated ceilings.
- Flicker-free per IEEE 1789-2015 (no observable adverse effects of flicker at 100% light output level).
- Complies with FCC Part 15, Class B.
- Inherently protected.
- IP6X rated for ingress protection.
WARRANTY
- 5-year warranty on all electronics and housing.
